upload details analysis

src/app/app.module.ts

@@ -93,6 +93,7 @@ import { UploadCardsComponent } from './upload-cards/upload-cards.component';
 import {UploadInterceptor} from './lender-uploads/upload-status.interceptor';
 import { UploadDetailComponent } from './upload-detail/upload-detail.component';
 import {SafeUrlPipe} from './pipe/safe.url.pipe';
+import { ImagePopupDialogComponent } from './image-popup-dialog/image-popup-dialog.component';



@@ -155,7 +156,8 @@ import {SafeUrlPipe} from './pipe/safe.url.pipe';
     ListIncomeComponent,
     UploadCardsComponent,
     UploadDetailComponent,
-    SafeUrlPipe
+    SafeUrlPipe,
+    ImagePopupDialogComponent
   ],
   imports: [
     BrowserModule,

src/app/dashboard/dashboard.component.scss

@@ -1,7 +1,7 @@
 .container.outer{
     width:100%;
     max-width:100vw;
-    background: url('/assets/img/body_bg.jpg') no-repeat center center fixed;
+    background: url('./assets/img/body_bg.jpg') no-repeat center center fixed;
     -webkit-background-size: cover;
     -moz-background-size: cover;
     -o-background-size: cover;

src/app/image-popup-dialog/image-popup-dialog.component.html

@@ -0,0 +1,18 @@
+<kendo-dialog [title]="title" *ngIf="opened" (close)="close('cancel')"
+              [minWidth]="'200px'"  [minHeight]="'200px'" [width]="dialogWidth"
+              [maxWidth]="'100vw'" [maxHeight]="'100vh'"
+>
+    <div class="text-center">
+      <kendo-loader *ngIf="!imageLoaded" size="large"></kendo-loader>
+    </div>
+    <img #content [src]="url | safeUrl"  (load)="onLoad()"   [width]="iWidth"/>
+
+  <kendo-dialog-actions>
+    <button kendoButton (click)="zoom(+0.1)" [icon]="'zoom-in'" [disabled]="imgWidthPercent >= 200 "><span class="k-fx-hidden">.</span></button>
+    <button kendoButton (click)="zoom(-0.1)" [icon]="'zoom-out'" [disabled]="imgWidthPercent <=0" ><span class="k-fx-hidden">.</span></button>
+    <button kendoButton (click)="originalSize()" >1:1</button>
+    <button kendoButton (click)="close('no')" [disabled]="true"></button>
+    <button kendoButton (click)="close('no')" [disabled]="true">{{imgWidthPercent | percent:'1.0'}}</button>
+    <button kendoButton (click)="close('yes')" [icon]="'close-circle'" primary="true">close</button>
+  </kendo-dialog-actions>
+</kendo-dialog>

src/app/image-popup-dialog/image-popup-dialog.component.spec.ts

@@ -0,0 +1,25 @@
+import { ComponentFixture, TestBed } from '@angular/core/testing';
+
+import { ImagePopupDialogComponent } from './image-popup-dialog.component';
+
+describe('ImagePopupDialogComponent', () => {
+  let component: ImagePopupDialogComponent;
+  let fixture: ComponentFixture<ImagePopupDialogComponent>;
+
+  beforeEach(async () => {
+    await TestBed.configureTestingModule({
+      declarations: [ ImagePopupDialogComponent ]
+    })
+    .compileComponents();
+  });
+
+  beforeEach(() => {
+    fixture = TestBed.createComponent(ImagePopupDialogComponent);
+    component = fixture.componentInstance;
+    fixture.detectChanges();
+  });
+
+  it('should create', () => {
+    expect(component).toBeTruthy();
+  });
+});

src/app/image-popup-dialog/image-popup-dialog.component.ts

@@ -0,0 +1,100 @@
+import {AfterViewInit, Component, ElementRef, HostListener, Input, OnInit, ViewChild} from '@angular/core';
+
+@Component({
+  selector: 'app-image-popup-dialog',
+  templateUrl: './image-popup-dialog.component.html',
+  styleUrls: ['./image-popup-dialog.component.scss']
+})
+export class ImagePopupDialogComponent implements OnInit{
+  @Input() url = '';
+  @Input() title = 'Image';
+  @ViewChild('content', { read: ElementRef }) img: ElementRef;
+  public opened = false;
+  public imgWidthPercent = 1;
+  public iWidth = 100;
+  public imgOriginalWidth = 0;
+  public imgOriginalHeight = 0;
+  public imageLoaded = false;
+  public scrHeight = 0;
+  public scrWidth = 0;
+  public dialogWidth = 0 ;
+  public margin = 32; // dialog margin;
+  constructor() { }
+
+  ngOnInit(): void {
+    this.getScreenSize();
+    this.initDialogWidth();
+  }
+
+
+  @HostListener('window:resize', ['$event'])
+  getScreenSize(event?): void {
+    this.scrHeight = window.innerHeight;
+    this.scrWidth = window.innerWidth;
+    this.dialogWidth = 200; // this.scrWidth;
+    // console.log(this.scrHeight, this.scrWidth);
+    // console.log(this.scrHeight, this.scrWidth);
+  }
+
+  public showImg(url: string, title?: string): void {
+    this.initDialogWidth();
+    this.title = title || 'Image';
+    const ts = Date.now();
+    this.url = url + '?date=' + ts;
+    this.opened = true;
+  }
+
+  private initDialogWidth(): void {
+    this.imageLoaded = false;
+    this.dialogWidth = 200;
+    this.iWidth = this.dialogWidth - this.margin;
+  }
+
+  public close(status: string): void {
+    this.opened = false;
+  }
+
+  public zoom(diff: number): void {
+    this.imgWidthPercent += diff;
+    if (this.imgWidthPercent < 0.05) {
+      this.imgWidthPercent = 0.05;
+    }
+    if (this.imgWidthPercent > 3){
+      this.imgWidthPercent = 3;
+    }
+    this.resizeWindow();
+  }
+
+  public originalSize(): void {
+    this.imgWidthPercent = 1;
+    this.resizeWindow();
+  }
+
+  private resizeWindow(): void {
+    this.iWidth = this.imgOriginalWidth * this.imgWidthPercent;
+    const margin = this.margin; // the default dialog padding
+    if (this.iWidth + margin <= this.scrWidth) {
+      this.dialogWidth = this.iWidth + margin;
+    }else{
+      this.dialogWidth = this.scrWidth;
+    }
+
+    console.log(this.img.nativeElement.naturalWidth, this.img.nativeElement.naturalHeight,
+      this.img.nativeElement.width, this.img.nativeElement.height, this.iWidth, this.imgWidthPercent);
+
+  }
+
+  public onLoad(): void {
+    this.imageLoaded = true;
+    this.imgOriginalWidth = this.img.nativeElement.naturalWidth;
+    this.imgOriginalHeight = this.img.nativeElement.naturalHeight;
+    if ( this.imgOriginalWidth > this.scrWidth) {
+      this.iWidth = this.scrWidth - this.margin;
+    }else{
+      this.iWidth = this.imgOriginalWidth;
+    }
+    this.imgWidthPercent = this.iWidth   / this.imgOriginalWidth;
+    this.resizeWindow();
+  }
+
+}

src/app/lender-uploads/lender-uploads.component.html

@@ -8,7 +8,7 @@
                     (uploadProgress)="uploadProgress($event)"
                     [showFileList]="false"
                     [saveUrl]="uploadSaveUrl">
-        <ng-template kendoUploadFileInfoTemplate let-files let map="map">
+        <ng-template kendoUploadFileInfoTemplate let-files>
           <div *ngIf="files!==undefined && files!== null && files[0] !== null">
             <div (click)="onClick(files)">Name: {{ files[0].name }}</div>
             <div *ngIf="files[0].validationErrors !== undefined"> Cannot upload this file {{files[0]}}</div>
@@ -24,11 +24,16 @@
   </div>
   <bkp-divider-shadow-bottom></bkp-divider-shadow-bottom>
   <div class="container">
-    <div class="row justify-content-start">
-      <div class="col-lg-3 text-center" *ngFor="let p of displayedUploads">
+    <div *ngIf="!loading" class="row justify-content-start">
+      <div  class="col-lg-3 text-center" *ngFor="let p of displayedUploads">
         <app-upload-cards [uploadId]="p"></app-upload-cards>
       </div>
     </div>
+    <div *ngIf="loading" class="row justify-content-center">
+      <div class="col-lg-1 text-center loader">
+        <kendo-loader [size]="'large'"></kendo-loader>
+      </div>
+    </div>
     <div class="vertical-spacer"></div>
   </div>

@@ -41,6 +46,4 @@
     (pageChange)="onPageChange($event)">
   </kendo-datapager>

-
-
 </div>

src/app/lender-uploads/lender-uploads.component.scss

@@ -3,6 +3,11 @@ div.workarea{
   position:relative;
   background-color: #46495b;
   overflow: scroll;
+
+  div.row div.loader{
+    top: 45%;
+    position:absolute;
+  }
 }

 div.file-manager-bar{

src/app/lender-uploads/lender-uploads.component.ts

@@ -4,6 +4,8 @@ import {AuthService} from '../service/auth.service';
 import {range} from '@progress/kendo-angular-dateinputs/dist/es2015/util';
 import {Router} from '@angular/router';
 import {PageChangeEvent} from '@progress/kendo-angular-pager';
+import {ImagePopupDialogComponent} from '../image-popup-dialog/image-popup-dialog.component';
+import {UploadAttachService} from '../service/upload.attach.service';

 @Component({
   selector: 'app-lender-uploads',
@@ -20,6 +22,7 @@ export class LenderUploadsComponent implements OnInit {
   private uploads: SuccessEvent[] = [];
   public  value = 0 ;
   public map: Map<string, SuccessEvent> = new Map<string, SuccessEvent>();
+  public loading = false;

   uploadSaveUrl = 'https://svr2021.lawipac.com:8080/api/v1/lender-upload/'; // should represent an actual API endpoint
   uploadRemoveUrl =  'https://svr2021.lawipac.com:8080/api/v1/lender-upload-remove/'; // should represent an actual API endpoint
@@ -37,7 +40,7 @@ export class LenderUploadsComponent implements OnInit {
     allowedExtensions: ['.pdf', '.xls', '.xlsx']
   };

-  constructor(private auth: AuthService, private router: Router) {
+  constructor(private auth: AuthService, private router: Router, private uas: UploadAttachService) {
   }


@@ -45,6 +48,7 @@ export class LenderUploadsComponent implements OnInit {
     this.uploadSaveUrl = this.auth.getUrl('lender-upload/');
     this.uploadRemoveUrl = this.auth.getUrl('lender-upload-remove/');
     this.loadDisplayedUploads();
+
   }


@@ -97,9 +101,22 @@ export class LenderUploadsComponent implements OnInit {
     this.filteredUploads = this.allUploads ;
     this.displayedUploads = this.filteredUploads.slice(this.skip, this.skip + this.pageSize);
     this.total = this.displayedUploads.length;
+
+  }
+
+  private loadAllUploads(): void{
+    this.loading = true;
+    // this.uas.getUploadMetaList(this.skip, this.skip + this.pageSize).subscribe(
+    //   resp => {
+    //     this.loading = false;
+    //   }
+    // );
+
   }

   public onFilterUploads(hint: string): void {
     this.loadDisplayedUploads();
   }
+
+
 }

src/app/models/analysis.aaa.model.ts

@@ -0,0 +1,19 @@
+
+export class AnalysisAaaModel {
+  Year: number;
+  Month: number;
+  LoanNumber: string;
+  Settlement: Date;
+  LoanAmount: number;
+  Balance: number;
+  InTrail: number;
+  constructor(payload: Partial<AnalysisAaaModel>) {
+    this.Year = payload.Year || 0;
+    this.Month = payload.Month || 0;
+    this.LoanNumber = payload.LoanNumber || '';
+    this.Settlement = new Date(payload.Settlement);
+    this.LoanAmount = payload.LoanAmount || 0;
+    this.Balance = payload.Balance || 0;
+    this.InTrail = payload.Year || 0;
+  }
+}

src/app/models/upload.analysis.model.ts

@@ -1,7 +1,7 @@
-import {UploadModel} from './upload.model';
+import {UploadMetaModel} from './uploadMetaModel';
 import {PayInModel} from './pay-in.model';
 import {FunderAaaTrailModel} from './funder.aaa.trail.model';
-import {PayInAAARowModel} from './Pay.In.AAA.Row.model';
+

 export class UploadAnalysisModel {
   public Id: number;
@@ -13,7 +13,7 @@ export class UploadAnalysisModel {

   public IsDuplicate: boolean;
   public Uid?: string;  // client side unique id when upload
-  public Input?: UploadModel;
+  public Input?: UploadMetaModel;

   constructor(payload: Partial<UploadAnalysisModel>){
     this.Id = payload.Id || 0 ;
@@ -44,7 +44,7 @@ export class UploadAnalysisModel {

     this.IsDuplicate = payload.IsDuplicate || false;
     this.Uid = payload.Uid || '' ;
-    this.Input = new UploadModel(payload.Input || {});
+    this.Input = new UploadMetaModel(payload.Input || {});
   }

 }

src/app/models/upload.model.ts → src/app/models/uploadMetaModel.ts

@@ -1,7 +1,7 @@

-export class UploadModel {
+export class UploadMetaModel {
   public Id: number;
-  public Mime: string;
+  public Format: string;
   public FileName: string;
   public Ts: Date;
   public By: string;
@@ -9,9 +9,9 @@ export class UploadModel {
   public Size: number;
   public Sha256: string;

-  constructor(payload: Partial<UploadModel>) {
+  constructor(payload: Partial<UploadMetaModel>) {
     this.Id = payload.Id || 0;
-    this.Mime = payload.Mime || '';
+    this.Format = payload.Format || '';
     this.FileName = payload.FileName || '';
     this.Ts = new Date (payload.Ts || new Date());
     this.By = payload.By || '';
@@ -19,4 +19,9 @@ export class UploadModel {
     this.Size = payload.Size || 0;
     this.Sha256 = payload.Sha256 || '';
   }
+
+  get iconUrl(): string {
+    const t = this.Format.replace( '/',  '-');
+    return location.origin +'/assets/img/mime/' + t + '.png';
+  }
 }

src/app/service/upload.attach.service.ts

@@ -2,7 +2,7 @@ import {Injectable} from '@angular/core';
 import {HttpClient} from '@angular/common/http';
 import {AuthService} from './auth.service';
 import {Observable} from 'rxjs';
-import {UploadModel} from '../models/upload.model';
+import {UploadMetaModel} from '../models/uploadMetaModel';
 import {UploadAnalysisModel} from '../models/upload.analysis.model';


@@ -11,8 +11,8 @@ export class UploadAttachService {
   constructor(private http: HttpClient, private auth: AuthService) {
   }

-  public getUploadMeta(id: number): Observable<UploadModel> {
-    return this.http.get<UploadModel>(this.auth.getUrl('upload-meta/' + id));
+  public getUploadMeta(id: number): Observable<UploadMetaModel> {
+    return this.http.get<UploadMetaModel>(this.auth.getUrl('upload-meta/' + id));
   }

   public getUploadAnalysis(id: number): Observable<UploadAnalysisModel> {
@@ -20,13 +20,23 @@ export class UploadAttachService {
   }

   public getUploadAsJpgUrl(id: number): string {
-    return this.auth.getUrl('upload-as-image/' + id);
+    const ts = Date.now();
+    return this.auth.getUrl('upload-as-image/' + id  + '?date=' + ts);
+  }
+
+  public getUploadAsJpgUrlDefault(): string {
+    return this.auth.getUrl('upload-as-image/default');
   }

   public getUploadAsPdfUrl(id: number): string {
     const ts = Date.now();
     return this.auth.getUrl('upload-as-pdf/' + id + '?date=' + ts);
   }
+  public getUploadAsPdfUrlDefault(): string {
+    const ts = Date.now();
+    return this.auth.getUrl('upload-as-pdf/default' + '?date=' + ts);
+  }
+
   public getUploadAsPdfUrlForDownload(id: number): string {
     return this.auth.getUrl('upload-as-pdf/' + id + '?download=force');
   }

src/app/upload-cards/upload-cards.component.html

@@ -1,6 +1,6 @@
 <div class="card-wrapper">
-  <div class="file-type-image" [ngStyle]="{'background-image': 'url(https://via.placeholder.com/32x32)'}"></div>
-  <kendo-card class="upload-card-content upload-thumb" [width]="'200px'"   [ngStyle]="{'background-image' : thumbImage}">
+  <div class="file-type-image" [ngStyle]="{'background-image': 'url('+ icon +')'}"></div>
+  <kendo-card class="upload-card-content upload-thumb" [width]="'200px'"   [ngStyle]="{'background-image' : 'url(' + thumbImage + ')'}">

     <kendo-card-header class="k-hbox">
       <p> some title </p>
@@ -17,6 +17,6 @@


   </kendo-card>
-
-
 </div>
+
+<app-image-popup-dialog #imgBox></app-image-popup-dialog>

src/app/upload-cards/upload-cards.component.scss

@@ -32,18 +32,17 @@ div.card-wrapper{
   }
   .file-type-image{
     width: 32px;
-    border-radius:100%;
+    // border-radius:100%;
     background-repeat: no-repeat;
     background-size: cover;
-    border:1px white solid;
-    box-shadow: inset 1px 1px 0 #b7b7b7;
+    // border:1px white solid;
+    // box-shadow: inset 1px 1px 0 #b7b7b7;

     z-index: 2;
-    width: 32px;
     height: 32px;
     position: absolute;
     margin-right: 10px;
-    right : 30px;
+    left : 160px;
     top: 20px;
   }


src/app/upload-cards/upload-cards.component.ts

@@ -1,5 +1,11 @@
-import {Component, Input, OnInit} from '@angular/core';
+import {Component, EventEmitter, Input, OnInit, Output, ViewChild} from '@angular/core';
 import {Router} from '@angular/router';
+import {ImagePopupDialogComponent} from '../image-popup-dialog/image-popup-dialog.component';
+import {AuthService} from '../service/auth.service';
+import {UploadMetaModel} from '../models/uploadMetaModel';
+import {UploadAttachService} from '../service/upload.attach.service';
+
+

 @Component({
   selector: 'app-upload-cards',
@@ -8,13 +14,25 @@ import {Router} from '@angular/router';
 })
 export class UploadCardsComponent implements OnInit {
   @Input() uploadId: number;
+  @Input() icon  = '../../assets/img/pdf.jpg';
+  @ViewChild('imgBox', {static: true}) imgBox: ImagePopupDialogComponent;
+  public uploadMeta: UploadMetaModel = new UploadMetaModel({});

-  public thumbImage = 'url(https://svr2021.lawipac.com:8080/api/v1/upload-as-thumbnail/31)';
+  public thumbImage = 'https://svr2021.lawipac.com:8080/api/v1/upload-as-thumbnail/31';
+  public fullImage = '';

-  constructor(private router: Router) { }
+  constructor(private router: Router, private auth: AuthService, private uas: UploadAttachService) { }

   ngOnInit(): void {
-    this.thumbImage = 'url(https://svr2021.lawipac.com:8080/api/v1/upload-as-thumbnail/' + this.uploadId + ')';
+    let url = this.auth.getUrl('upload-as-thumbnail/' + this.uploadId);
+    this.thumbImage = url ;
+    url = this.auth.getUrl('upload-as-image/' + this.uploadId);
+    this.fullImage = url;
+
+    this.uas.getUploadMeta(this.uploadId).subscribe( resp => {
+      this.uploadMeta = new UploadMetaModel(resp);
+      this.icon = this.uploadMeta.iconUrl;
+    });
   }

   public onNavigateTo(id: number ): void{
@@ -24,6 +42,12 @@ export class UploadCardsComponent implements OnInit {
     this.router.navigate(['/upload-details/' + id]);
   }
   public onSearch(id: number ): void{
-    this.router.navigate(['/upload-details/' + id]);
+    this.popupImage(this.fullImage);
+    // this.popupImage(this.thumbImage);
   }
+
+  public popupImage(url: string): void {
+    this.imgBox.showImg(url, this.uploadId + ' - ' + this.uploadMeta.FileName);
+  }
+
 }

src/app/upload-detail/upload-detail.component.html

@@ -1,57 +1,100 @@
 <div class="workspace">
-  <kendo-tabstrip [tabPosition]="'left'" class="fullheight-tab upload-details"
-                  (tabSelect)="onTabSelect($event)"
-                  [animate]="false"
-  >
-    <kendo-tabstrip-tab title="PreView" [selected]="true">
-      <ng-template kendoTabContent>
-        <div class="dark-panel text-center" >
-          <div class="main-image-content" >
-            <img [src]="uploadAsPicUrl | safeUrl">
-          </div>
-        </div>
-      </ng-template>
-    </kendo-tabstrip-tab>
-
-    <kendo-tabstrip-tab title="Content"  cssClass="uploads-panel">
-      <ng-template kendoTabContent class="dark-panel">
-        <div class="dark-panel text-center">
-          <div  class="main-content" [ngClass]="{'init-pdf': !initAnimation, 'ready-pdf': initAnimation}">
-            <kendo-loader *ngIf="!iframeLoaded || !initAnimation" [size]="'large'"></kendo-loader>
-            <iframe #pdf height="100%"
-                    [ngClass]="{'init-iframe': !iframeLoaded, 'ready-iframe': iframeLoaded}"
-                    [src]="uploadAsPdfUrl | safeUrl"
-                    (loadstart)="finishedLoading('loadstart')"
-                    (load)="finishedLoading('load')" ></iframe>
-          </div>
-        </div>
-      </ng-template>
-    </kendo-tabstrip-tab>
-
-    <kendo-tabstrip-tab title="AI Analysis">
-      <ng-template kendoTabContent>
-        <div *ngIf="!scandone" class="dark-panel text-center" >
-          <div *ngIf="scanning" class="overlay" [ngClass]="{'scanning': scanning, 'fade-out': scandone }"></div>
-          <div *ngif="!scandone" class="main-content" [ngClass]="{'init-pdf': !initAnimation, 'ready-pdf': initAnimation, 'fade-out': scandone}">
-            <kendo-loader *ngIf="!iframeLoaded || !initAnimation" [size]="'large'"></kendo-loader>
-            <iframe #pdf height="100%"
-                    [ngClass]="{'init-iframe': !iframeLoaded, 'ready-iframe': iframeLoaded}"
-                    [src]="uploadAsPdfUrl | safeUrl"
-                    (loadstart)="finishedLoading('loadstart')"
-                    (load)="finishedLoading('load')" ></iframe>
-          </div>
-        </div>
-        <p> {{ ua.Input.FileName }}</p>
-        <p> {{ ua.Input.Id }}</p>
-
-      </ng-template>
-    </kendo-tabstrip-tab>
-
-  </kendo-tabstrip>
-
-
-  <kendo-floatingactionbutton #fab class="init-fab" [ngClass]="{'init-fab': !initAnimation, 'ready-fab': initAnimation}"
+  <kendo-splitter orientation="vertical">
+
+    <kendo-splitter-pane [resizable]="true" >
+      <div class="pane-content">
+        <kendo-tabstrip #tabs [tabPosition]="'left'" class="fullheight-tab upload-details"
+                        (tabSelect)="onTabSelect($event)"
+                        [animate]="true"
+        >
+          <kendo-tabstrip-tab [title]="tabTitle[0]" [selected]="true">
+            <ng-template kendoTabContent>
+              <div class="dark-panel text-center preview" >
+                <div *ngIf="!PreviewImgLoaded" class="text-center">
+                  <kendo-loader size="large"></kendo-loader>
+                </div>
+                <div class="main-image-content"
+                     [ngClass]="{'image-not-loaded': !PreviewImgLoaded, 'image-loaded': PreviewImgLoaded }" >
+                  <img [src]="uploadAsPicUrl | safeUrl" (load)="onImgPreviewLoaded()">
+                </div>
+              </div>
+            </ng-template>
+          </kendo-tabstrip-tab>
+
+          <kendo-tabstrip-tab [title]="tabTitle[1]"  cssClass="uploads-panel">
+            <ng-template kendoTabContent class="dark-panel">
+              <div class="dark-panel text-center">
+                <div  class="main-content" [ngClass]="{'init-pdf': !initAnimation, 'ready-pdf': initAnimation}">
+                  <kendo-loader *ngIf="!iframeLoaded || !initAnimation" [size]="'large'"></kendo-loader>
+                  <iframe #pdf height="100%"
+                          [ngClass]="{'init-iframe': !iframeLoaded, 'ready-iframe': iframeLoaded}"
+                          [src]="uploadAsPdfUrl | safeUrl"
+                          (loadstart)="finishedLoading('loadstart')"
+                          (load)="finishedLoading('load')" ></iframe>
+                </div>
+              </div>
+            </ng-template>
+          </kendo-tabstrip-tab>
+
+          <kendo-tabstrip-tab [title]="tabTitle[2]">
+            <ng-template kendoTabContent>
+              <div *ngIf="!scanDone" class="dark-panel text-center preview" >
+                <div *ngIf="!ScanImgLoaded" class="text-center">
+                  <kendo-loader size="large"></kendo-loader>
+                </div>
+                <div *ngIf="scanning" class="overlay"
+                     [ngClass]="{'scanning': scanning, 'fade-out': scanDone }">
+                  <hr class="red-scan-line" />
+                </div>
+                <div *ngIf="!scanDone || scanning" class="main-image-content"
+                     [ngClass]="{'image-not-loaded': !ScanImgLoaded, 'image-loaded': ScanImgLoaded }"  >
+                  <img [src]="uploadAsPicUrl | safeUrl" (load)="onImgScanLoaded()">
+                </div>
+              </div>
+              <div *ngIf="scanDone" class="analysis-result">
+                <kendo-grid *ngIf="ua.Funder ==='AAA Financial'" [data]="analysisAAA">
+                  <ng-template kendoGridToolbarTemplate>
+                    {{ua.Funder }}
+                    <button kendoGridAddCommand icon="plus" >Add new Income</button>
+                    &nbsp; Show Uploads &nbsp; <kendo-switch></kendo-switch>
+                  </ng-template>
+                  <kendo-grid-column field="Year"> </kendo-grid-column>
+                  <kendo-grid-column field="Month"> </kendo-grid-column>
+                  <kendo-grid-column field="LoanNumber"> </kendo-grid-column>
+                  <kendo-grid-column field="Settlement"> </kendo-grid-column>
+                  <kendo-grid-column field="Amount"> </kendo-grid-column>
+                  <kendo-grid-column field="Balance"> </kendo-grid-column>
+                  <kendo-grid-column field="InTrail"> </kendo-grid-column>
+                </kendo-grid>
+                <div *ngIf="ua.Funder ===''">
+                  <kendo-grid> </kendo-grid>
+                </div>
+              </div>
+
+            </ng-template>
+          </kendo-tabstrip-tab>
+
+        </kendo-tabstrip>
+      </div>
+    </kendo-splitter-pane>
+
+    <kendo-splitter-pane [resizable]="true" [collapsible]="true" [collapsed]="!resizeSplitter"
+                         (collapsedChange)="onPayInCollapsed($event)"
+                         (sizeChange)="onPayInSizeChange($event)"
+                         [(size)]="PayInSize">
+      <div class="pane-content">
+        <h3>Outer splitter / Bottom pane</h3>
+        <p>Non-resizable and non-collapsible.</p>
+      </div>
+    </kendo-splitter-pane>
+  </kendo-splitter>
+
+
+
+  <kendo-floatingactionbutton #fab class="init-fab"
+      [ngClass]="{'init-fab': !initAnimation && !resizeSplitter, 'ready-fab': initAnimation &&!resizeSplitter}"
                               [icon]="'table'"
+                              [offset]="fabOffset"
                               [align]="{ horizontal: 'start', vertical: 'bottom' }"
                               (click)="onClickFloatActionButton($event)"
                               [title]="'List all Uploads'"
@@ -60,3 +103,6 @@
   >
   </kendo-floatingactionbutton>
 </div>
+
+
+

src/app/upload-detail/upload-detail.component.scss

@@ -5,6 +5,13 @@
 div.workspace {
   height: calc(100vh - 48px);
   overflow: hidden;
+  kendo-splitter {
+    height:100%;
+    .pane-content{
+      height:100%;
+    }
+  }
+
 }

 .fullheight-tab{
@@ -21,6 +28,11 @@ div.workspace {
   overflow: hidden;
   position:relative;

+  &.preview{
+    height: unset;
+    min-height: 100%;
+  }
+
   .main-content,
   .main-image-content{
     position:relative;
@@ -34,7 +46,7 @@ div.workspace {
   .main-image-content{
     display:block;
     text-align: center;
-    overflow: scroll;
+    margin-bottom: 30px;
     img {
       width:100%;
     }
@@ -72,11 +84,14 @@ div.workspace {
     transition: all 0.1s ease-in-out;
   }

+}

+kendo-floatingactionbutton {
+  width: 52px;
 }

 .init-fab{
-  top : -10px !important;
+  top : 50vh !important;
   transition: all 1s ease-in-out;
 }

@@ -86,24 +101,87 @@ div.workspace {
 }

 div.overlay {
-  height: 10%;
-  background-color: black;
+  height: 100px;
+  background-color: #19c7ef;
   opacity: 0.5;
   z-index: 10;
-  position: absolute;
   width: 100%;
+  background-image: url('../../assets/img/scanbar.gif');
+  background-size: cover;
+  background-repeat: no-repeat;
+  position: absolute;
+  top:20px;
+  background-blend-mode: color; // for background image
+  mix-blend-mode: hard-light; // for background
 }
+
 .scanning{
-  animation: scanning 1s infinite;
+   animation: scanning 3s infinite;
+}
+
+.image-not-loaded{
+  top: 100vh;
+}
+.image-loaded{
+  top: 0;
 }

 @keyframes scanning {
   50% {
-    transform: translateY(80vh);
+    transform: translateY(100vh);
   }
 }

+@keyframes shrinking {
+  50% {
+    height: 10px;
+    background-color: yellow;
+  }
+}
+
+
 .fade-out {
   opacity: 0;
   transition: all 0.5s ease-out;
 }
+
+.blink_me {
+  animation: blinker 1s linear infinite;
+}
+
+.red-scan-line{
+  color: red;
+  width: 100%;
+  border-top: 3px solid red;
+  box-shadow: 1px 1px 10px red;
+  animation: blinker 0.1s linear infinite;
+  position: absolute;
+  top: 80%;
+}
+@keyframes blinker {
+  50% {
+    opacity: 0.1;
+  }
+}
+
+.scanning > .red-scan-line {
+  animation: top-down 3s infinite;
+}
+
+@keyframes top-down {
+  0%  {  top:80%;}
+  49% {  top:80%; }
+  50% {  top: 0;  }
+  99% {  top: 0;  }
+  100%{  top: 80%;}
+}
+
+
+div.analysis-result{
+  height: 100%;
+  width: 100%;
+  background-color: lightgoldenrodyellow;
+  kendo-grid{
+    height: 100%;
+  }
+}

src/app/upload-detail/upload-detail.component.ts

@@ -1,10 +1,11 @@
-import {Component, ElementRef, Input, OnInit, ViewChild, ViewEncapsulation} from '@angular/core';
+import {AfterViewChecked, AfterViewInit, Component, ElementRef, Input, OnInit, ViewChild, ViewEncapsulation} from '@angular/core';
 import {ActivatedRoute, Router} from '@angular/router';
 import {UploadAttachService} from '../service/upload.attach.service';
 import {UploadAnalysisModel} from '../models/upload.analysis.model';
-import {UploadModel} from '../models/upload.model';
+import {UploadMetaModel} from '../models/uploadMetaModel';
 import {FloatingActionButtonComponent} from '@progress/kendo-angular-buttons';
-import {DrawerSelectEvent} from '@progress/kendo-angular-layout';
+import {DrawerSelectEvent, TabStripComponent} from '@progress/kendo-angular-layout';
+import {AnalysisAaaModel} from '../models/analysis.aaa.model';



@@ -13,18 +14,34 @@ import {DrawerSelectEvent} from '@progress/kendo-angular-layout';
   templateUrl: './upload-detail.component.html',
   styleUrls: ['./upload-detail.component.scss']
 })
-export class UploadDetailComponent implements OnInit {
+export class UploadDetailComponent implements OnInit, AfterViewInit {
   @Input() uploadId: number;
   @Input() ua: UploadAnalysisModel = new UploadAnalysisModel({});
   @ViewChild('fab', {static: true}) fab: FloatingActionButtonComponent;
   @ViewChild('pdf', {static: false}) pdf: ElementRef;
+  @ViewChild('tabs', {static: true}) tab: TabStripComponent;
   // 'http://africau.edu/images/default/sample.pdf';
   public uploadAsPicUrl =  'https://svr2021.lawipac.com:8080/api/v1/upload-as-pdf/default';
   public uploadAsPdfUrl = '';
   public initAnimation = false;
   public iframeLoaded = false;
   public scanning = false;
-  public scandone = false;
+  public scanDone = false;
+  public analysisIsDone = false;
+
+  public ScanImgLoaded = false;
+  public PreviewImgLoaded = false;
+
+  public resizeSplitter = false;
+  public PayInSize = '300px';
+  public fabOffset = { x: '10px', y: this.PayInSize };
+
+  @Input() public currentTab = 0;
+  public tabText: string[] = ['Preview', 'Content', 'Analysis'];
+  public tabTitle: string[] = this.tabText;
+
+  public analysisAAA: AnalysisAaaModel[] = [];
+
   constructor(private us: UploadAttachService, private actRoute: ActivatedRoute, private router: Router) { }

   ngOnInit(): void {
@@ -40,29 +57,60 @@ export class UploadDetailComponent implements OnInit {
     }

     this.loadUploadMeta();
-    // this.loadUploadAnalysis();
-    // this.fabOffset  = { y : '-1px' };
     this.fabSlideIn();
+    // this.changeTabTitle();
+
+    // this.currentTab=2;
+
+    setTimeout(() => {
+        this.resizeSplitter = true;
+    }, 2000);
+  }
+
+  ngAfterViewInit(): void {
+    setTimeout(() => { // if I don't use this, it complains value has been changed after being checked.
+      this.tab.selectTab(this.currentTab);
+    }, 100);
   }

   private loadUploadAnalysis(): void  {
+    this.analysisIsDone = false;
     this.us.getUploadAnalysis(this.uploadId).subscribe(
       resp => {
-          this.scandone = true;
-          this.scanning = false;
-          this.ua = new UploadAnalysisModel(resp);
-          this.uploadId = this.ua.Id;
+       this.ua = new UploadAnalysisModel(resp);
+       // this.TranslateForDisplay()  // TODO: use database for this structure
+       this.uploadId = this.ua.Id;
+       this.analysisIsDone = true;
+      }, err => {
+        this.analysisIsDone = true;
+      }, () => {
+        this.analysisIsDone = true;
       }
     );
   }
   private loadUploadMeta(): void {
     this.us.getUploadMeta(this.uploadId).subscribe(
       resp => {
-        this.ua.Input = new UploadModel(resp);
+        this.ua.Input = new UploadMetaModel(resp);
       }
     );
   }

+  private startScanningUI(): void {
+    this.resizeSplitter = false;
+    this.scanning = true;
+    let count = 0;
+    const t = setInterval(() => {
+      count ++;
+      if (count > 30 && this.analysisIsDone) {  // 30 should be in sync with scss 3s
+        this.scanDone = true;
+        this.scanning = false;
+        this.resizeSplitter = true;
+        clearInterval(t);
+      }
+    }, 100);
+  }
+
   private fabSlideIn(): void {
     setTimeout(() => {this.initAnimation = true; }, 1000);
   }
@@ -72,24 +120,53 @@ export class UploadDetailComponent implements OnInit {
   }

   public finishedLoading(status: string ): void{
-    if ( this.pdf === undefined )  {
+    if (this.pdf === undefined) {
       return;
     }
-     const el = this.pdf.nativeElement;
-     if ( el !== undefined && el.src === this.uploadAsPdfUrl) {
-       console.log('yes true',this);
-       this.iframeLoaded = true;
-     }
+    const el = this.pdf.nativeElement;
+    if (el !== undefined && el.src === this.uploadAsPdfUrl) {
+      console.log('yes true', this);
+      this.iframeLoaded = true;
+    }
   }
   public onTabSelect( select: DrawerSelectEvent): void {
-    if ( select.index === 2 && ! this.iframeLoaded ) {
-      select.preventDefault();
-      return;
-    }
-    if ( ! this.scandone ) {
-      this.scanning = true;
+    this.currentTab = select.index;
+    this.changeTabTitle();
+    if ( select.index === 2 &&  ! this.scanDone ) {
       this.loadUploadAnalysis();
     }
+  }
+
+  private changeTabTitle(): void {
+    this.tabTitle = [];
+    for ( let i = 0; i < this.tabText.length; i++ ) {
+      if ( i === this.currentTab ){
+        this.tabTitle[i] = '☒ ' + this.tabText[i];
+      }else{
+        this.tabTitle[i] = '☐ ' + this.tabText[i];
+      }
+    }
+  }
+
+  public onImgPreviewLoaded(): void {
+    this.PreviewImgLoaded = true;
+  }
+
+  public onImgScanLoaded(): void {
+    this.ScanImgLoaded = true;
+    this.startScanningUI();
+  }
+
+
+
+  public onPayInCollapsed( closed: boolean): void {
+    console.log(this);
+    this.resizeSplitter = !closed;
+    return ;
+  }

+  public onPayInSizeChange(s: string): void {
+    this.resizeSplitter = true;
+    this.fabOffset = {x: '10px', y: s};
   }
 }
